365nm UV Light Strip 5mm 60LED/m
Product Details Description
The LS-UVA365-60D-5MM is a 365nm uv light strip specially designed for B2B lighting projects, display manufacturers, inspection equipment manufacturers, cabinet manufacturers, sign companies, and OEM projects that need narrow UVA strip light with flexible customization. The led chips of this uv light strip are SMD2835 chips and it has 60 LEDs per meter and 5 meters per roll.
For applications where fluorescent effect is needed and visible purple light isn’t so much necessary, 365nm wavelength is applicable. This uv light strip is suitable for mineral & gemstone display, uranium glass cabinet, UV reactive shelf, resin curing, UV glue curing, anti-counterfeit check, leak detection, artwork display, lab style visual check, etc.
This strip is especially useful for spaces where 8mm or 10mm strip may be too wide to use because its PCB width is 5mm. The dimension of each roll is 5000 x 5 x 1.7mm and it is suitable for display edges, narrow shelves, narrow signs, cabinet grooves, slim aluminum profiles, slim channels, and equipment integration. 120° emission angle is beneficial for spreading UVA light to the target area and 10nm spectrum FWHM helps controlling the 365nm UVA output.
Unlike high-density 120LED/m models, 60LED/m structure reduces the power and the cost for projects where extremely dense light points aren’t necessary. The 7W/m working power of this uv light strip can help reducing the power demand and the heat load for projects.
This model is able to support 12V, 24V, 5V, or customized input voltage according to your project requirement. You can also customize the connection according to your controller, connector, wiring length, soldering process, power system, and product casing. This makes the LS-UVA365-60D-5MM uv light strip suitable for OEM projects.
With 4oz copper PCB, the current carrying capacity and heat dissipation will be improved, which is good for long-time or narrow uv light strip application. To ensure long-time performance, please use a proper constant-voltage power supply, make sure there is no excessive voltage drop on long runs, and install the uv light strip on an aluminum profile or other heat-dissipating surfaces.
The standard IP level is IP20 for indoor application. Waterproof protection can be customized if you want to protect the uv light strip from moisture, dust, or special installation environment. The performance is finally decided by the strip length, wiring way, voltage stability, power supply quality, ambient temperature, installation surface, etc.
This is a UVA product, not a UVC sterilization light. Please don’t use or advertise it for disinfection. Please avoid looking directly at the LED during operation and use proper safety procedures in commercial and industrial application.
The samples of this uv light strip can be provided for wavelength testing, brightness comparison, curing test, fluorescence effect check, installation check, and OEM project confirmation. If your project needs a 365nm uv light strip with SMD2835 LED chips, 60LED/m density, 5mm narrow PCB, customized input voltage, customized connection, or waterproof protection, LS-UVA365-60D-5MM can be customized.
Specifications
Model NO.: LS-UVA365-60D-5MM
Wavelength: 365nm
LED Chip: SMD2835
LED Quantity: 60led/m
Input Voltage: 12V / 24V / 5V or customizable
Working Power: 7W/m
Size: 5000 x 5 x 1.7mm
Emission Angle: 120°
Waterproof: IP20 or customizable
Spectrum FWHM: 10nm
PCB Copper Thickness: 4oz
Connection: Customizable
Samples: Available
FAQ
What is this uv light strip used for?
This uv light strip is used for fluorescence detection, UV-reactive display, mineral display, uranium glass cabinet, resin curing, UV glue curing, anti-counterfeit check, leak detection, artwork effects, signage, and OEM UV light strip projects.
What wavelength does the LS-UVA365-60D-5MM use?
This model uses 365nm UVA wavelength, which is commonly chosen for professional fluorescence response and visual inspection applications.
Is this UV light strip suitable for sterilization?
No. This is a 365nm UVA strip light, not a UVC sterilization light. Please don’t use it for disinfection or germicidal claims.
What LED chip is used?
This model uses SMD2835 LED chips with 60 LEDs per meter.
What is the strip width?
The strip width is 5mm and this uv light strip is suitable for narrow channel, compact display edge, narrow cabinet groove, acrylic signage, and installation space.
What voltage options are available?
This strip is suitable for 12V, 24V, 5V, or customized input voltage options.
What is the working power?
The working power of this uv light strip is 7W/m and it is suitable for projects needing a balance of UV output, power use, and heat control.
Is the strip waterproof?
The standard version is IP20 for indoor dry environment. Waterproof protection can be customized according to project requirements.
Why use 4oz copper PCB?
The 4oz copper PCB is beneficial for improving the current carrying capacity and heat spreading, which can help the strip run more stably.
Can the connection be customized?
Yes. The connection can be customized according to OEM assembly, controller matching, wiring way, connector, or private-label products.
Are samples available?
Yes. The samples can be provided for wavelength testing, brightness evaluation, curing test, fluorescence comparison, installation testing, and OEM project confirmation.
