YOYO UV offers OEM/ODM UV LED modules for equipment manufacturers and project teams working on curing, water treatment, disinfection and UV inspection. Share your application, target wavelength and installation requirements to discuss a suitable module configuration and request a project-specific quotation.
Include a drawing or reference module if available. If some specifications are still unknown, send the information you have.
UV LED modules for curing
For printing, coatings, adhesives and production equipment, begin with the response of the ink, resin or adhesive. Wavelength options listed for our curing modules include 365 nm, 385 nm and 395 nm UV LEDs, plus 405 nm violet LEDs. The suitable option depends on the material and process.
Provide the illuminated area, working distance, required irradiance or dose, exposure time or line speed, and cooling conditions. These inputs help define the module layout, optics, driver and thermal requirements for the proposed configuration.
UV LED modules for water treatment and disinfection
For water, air or surface treatment equipment, discuss the UV-C wavelength, optical arrangement and operating conditions together. A module specification alone does not establish the performance of a complete treatment system.
For water projects, include flow rate, water quality or UV transmittance if known, chamber dimensions and the treatment target. For air or surfaces, include airflow or exposure time, target area, working distance and enclosure design. Define the required dose, safety provisions and application-specific validation for the finished system.
UV LED modules for fluorescence and inspection
Choose the wavelength around the material or feature being inspected. Fluorescence inspection, crack detection and document examination have different optical requirements; a disinfection module is not automatically suitable for an inspection task.
Send a description of the target material, required wavelength if known, viewing or camera arrangement, illumination area and working distance. Include filter requirements and acceptable ambient light conditions where relevant. The linked 365 nm module is a product example; suitability must be assessed for the intended process.
What to include in an OEM/ODM enquiry
A clear requirement brief makes it easier to discuss a configuration and prepare a project-specific quotation.
| Requirement | Information to share |
|---|---|
| Application and target result | Curing material, inspection task or treatment objective; describe how the result will be evaluated. |
| Wavelength and optical output | Target wavelength, irradiance, dose or radiant power if known. Distinguish optical output from electrical input power, and include measurement distance and area. |
| Mechanical layout | Available space, module dimensions, mounting points, connector location and a drawing or reference module. |
| Electrical supply and control | Input voltage/current, driver or control interface, and expected duty cycle. |
| Operating environment | Ambient temperature, cooling method, enclosure and any water or dust exposure requirements. |
| Quantity and project schedule | Sample quantity, estimated production volume, target schedule and destination market. |
Availability, feasibility, sample cost, minimum order quantity and lead time need to be confirmed for the proposed configuration.
Plan the configuration and evaluation
The scope and evaluation steps are agreed for each project. A planning discussion can cover:
- Share the application requirements and available drawings or reference products.
- Discuss the proposed module configuration and resolve the key mechanical, optical and electrical questions.
- Agree the sample specification, evaluation method and quotation before placing an order.
- Confirm production specifications after the sample has been evaluated for the intended equipment.
The quotation confirms the agreed scope, quantities and schedule. Application performance must be evaluated under the intended operating conditions.
OEM/ODM questions
Which curing wavelengths can I ask about?
The curing options listed here include 365 nm, 385 nm and 395 nm UV LEDs, plus 405 nm violet LEDs. Send the material’s recommended wavelength and process conditions so the configuration can be reviewed.
Can dimensions, cooling and electrical connections be customized?
Send a drawing, input supply details, mounting constraints and cooling conditions with your request. The proposed mechanical, optical and electrical configuration needs to be confirmed for the project.
What are the minimum order quantity and lead time?
They depend on the module configuration, sample requirements and order volume. Include your quantities and target schedule in the enquiry and request a project-specific quotation.
Does a UV-C module guarantee disinfection performance?
No. The finished system’s result depends on wavelength, delivered dose, geometry, operating conditions and the target application. Define the evaluation method and safety requirements before selecting the module.
Discuss your UV LED project
Email info@yoyo-uv.com with your application, wavelength, drawing or reference product, quantities and target schedule. YOYO UV can review the information with you before a configuration and quotation are agreed.
