led 310nm UV COB led board module 20W
Product Description
The DB310T3WPS80-3535Fx4 2H8P-20MM is a led 310nm UVB module designed for compact ultraviolet light source applications. It is suitable for OEM device manufacturers, research equipment developers and industrial customers who need a defined 310nm UVB LED module with stable electrical and optical specifications.
This led 310nm module has a wavelength of 310nm. The 310nm output is in the UVB range and can be used in equipment designs that require controlled UVB exposure. For medical-related product development, this module should be treated as a light source component, not as a finished treatment device.
The module size is 20mm, and the net weight is 50g. This compact format supports integration into small UVB devices, prototype systems, test platforms, laboratory instruments and customized OEM ODM ultraviolet equipment. The smaller size also helps designers build space-saving optical structures.
The voltage is 14V, and the current is max 1500mA. The maximum electrical power is 20W, and the radiant power is 400mW. These parameters make the led 310nm module suitable for systems that require controlled UVB output, proper driver design and reliable thermal management.
The view angle is 120 degree. This wider beam angle helps provide broader irradiation coverage in research devices and prototype equipment. If a narrower beam, more even exposure or specific dose area is required, the final system can use optical lenses, reflectors, shielding design or distance control.
The lifespan is 30000 hours. Compared with traditional UVB lamp designs, a 310nm UVB LED module can support compact electronic integration, instant switching, smaller equipment structures and customized optical layouts. Actual performance depends on current control, heat dissipation, working environment and final system design.
This led 310nm product is suitable for scientific UVB research, biological testing, controlled irradiation platforms, agriculture research and OEM UVB light source development. It can also be considered for phototherapy device design, but final medical use requires professional dose control, safety protection, clinical validation and regulatory approval.
Factory OEM ODM service is available for customized 310nm UVB LED projects. Customers should confirm voltage, current, heat dissipation, working distance, optical layout, exposure time and UV safety requirements before mass production. Samples or prototype testing are recommended before final equipment design.
For buyers searching for led 310nm products with 310nm wavelength, 20mm size, 14V voltage, max 1500mA current, max 20W power, 400mW radiant power, 120 degree view angle, 30000 hours lifespan and factory OEM ODM service, the DB310T3WPS80-3535Fx4 2H8P-20MM provides a practical UVB LED light source for research, testing and customized equipment integration.
Specifications
Model No.: DB310T3WPS80-3535Fx4 2H8P-20MM
Wavelength: 310nm
Size: 20mm
Voltage: 14V
Current: Max 1500mA
Power: Max 20W
Radiant Power: 400mW
View Angle: 120 degree
Lifespan: 30000 hours
Net Weight: 50g
Factory OEM ODM Service: Available
FAQ
1. What is DB310T3WPS80-3535Fx4 2H8P-20MM?
It is a led 310nm UVB module designed as a compact ultraviolet light source for OEM device design, scientific research and controlled UVB equipment.
2. What is the wavelength?
The wavelength is 310nm.
3. Is 310nm UVB or UVC?
310nm is in the UVB range.
4. What is the module size?
The size is 20mm.
5. What voltage does the module use?
The voltage is 14V.
6. What is the maximum current?
The current is max 1500mA.
7. What is the maximum power?
The power is max 20W.
8. What is the radiant power?
The radiant power is 400mW.
9. What is the view angle?
The view angle is 120 degree.
10. What is the lifespan?
The lifespan is 30000 hours.
11. What is the net weight?
The net weight is 50g.
12. Can this led 310nm module be used for research equipment?
Yes. It can be used as a UVB LED light source for scientific research equipment when proper shielding, calibration and safety procedures are applied.
13. Can it be used for OEM device design?
Yes. Factory OEM ODM service is available for customized UVB LED module and equipment integration projects.
14. Can it be used for phototherapy device development?
It can be used as a 310nm UVB light source component for OEM phototherapy device design. Final medical use requires professional dose control, safety design, clinical validation and regulatory approval.
15. What should be considered during integration?
Use a suitable constant current driver, design proper heat dissipation, confirm exposure distance, add UV protection and test optical performance before mass production.
